Tree of Life QC: Species Report - Selenia tetralunaria

Below is information about specimens collected for this species retrieved from the Golden Record manifest.

NCBI taxon id:	934895
Order:	Lepidoptera
Family:	Geometridae
NCBI lineage:	Eukaryota;Metazoa;Ecdysozoa;Arthropoda;Hexapoda;Insecta;Pterygota;Neoptera;Endopterygota;Lepidoptera;Glossata;Ditrysia;Geometroidea;Geometridae;Ennominae;Selenia;
GoaT genome size (M):	831 (ancestor)
GoaT asm span (M):	1,030 (ancestor)
GoaT chr no.:	58 (direct)
ToLID prefix:	ilSelTetr

public_name	specimen_id	gal	sex	organism_part	biosample	biospecimen
ilSelTetr1	Ox000607	UNIVERSITY OF OXFORD	NOT_COLLECTED	ABDOMEN	SAMEA7701644	SAMEA7701471
ilSelTetr1	Ox000607	UNIVERSITY OF OXFORD	NOT_COLLECTED	THORAX	SAMEA7701643	SAMEA7701471
ilSelTetr1	Ox000607	UNIVERSITY OF OXFORD	NOT_COLLECTED	HEAD	SAMEA7701643	SAMEA7701471

Below are estimates of genome size, repeat size, heterozygosity based on k-mer specta analysis with GenomeScope.

source	specimen	k-mer	k-cov	haploid size	repeat (%)	heterozygosity (%)	model fit (%)	model error (%)
10x	ilSelTetr1	31	16.59	1,106,672,055	42.67	0.87	99.41	0.45
pacbio	ilSelTetr1	31	41.16	27,315,001	86.81	3.39	88.95	4.11
hic-arima2	ilSelTetr1	31	66.74	664,723,390	0.00	100.00	5.48	0.11

pipeline	specimen	date	run id	movie	well	tag	yield	N50	sample accession	run accession	barcode
PacBio - HiFi	ilSelTetr1	2021-05-14	82303	m64221e_210514_185712	B01	1010	8,285,454,611	8,932	SAMEA7701644

id	taxon	similarity	seq	country	latitude	longitude
GWOR4455-09	Selenia tetralunaria	0.9985	COI-5P	Austria	47.725	13.599
LON5432-16	Selenia tetralunaria	0.9985	COI-5P	Norway	58.1611	8.09929
CGUKA613-09	Selenia tetralunaria	0.9985	COI-5P	United Kingdom	54.19	-2.8
CGUKA813-09	Selenia tetralunaria	0.9985	COI-5P	United Kingdom	[object Object]	[object Object]
GWOSI019-10	Selenia tetralunaria	0.9985	COI-5P	Croatia	44.8	15.7167
LEFIE166-10	Selenia tetralunaria	0.9985	COI-5P	Finland	67.276	23.753
LEFIF206-10	Selenia tetralunaria	0.9985	COI-5P	Finland	59.836	23.236
LEFIA234-10	Selenia tetralunaria	0.9985	COI-5P	Finland	61.108	28.799
LENOA1070-11	Selenia tetralunaria	0.9985	COI-5P	France	49.547	1.56
PHLAV024-12	Selenia tetralunaria	0.9985	COI-5P	Austria	47.267	9.667

pipeline	specimen	date	run id	read pairs	yield	sample accession	run status	barcode
Chromium genome	ilSelTetr1	2021-05-26	38128_3#18	99,263,490	14,988,786,990	SAMEA7701644	qc complete
Chromium genome	ilSelTetr1	2021-05-26	38128_3#19	99,035,578	14,954,372,278	SAMEA7701644	qc complete	Selenia tetralunaria (1.00)
Chromium genome	ilSelTetr1	2021-05-26	38128_3#17	97,380,008	14,704,381,208	SAMEA7701644	qc complete
Chromium genome	ilSelTetr1	2021-05-26	38128_3#20	86,748,982	13,099,096,282	SAMEA7701644	qc complete	Selenia tetralunaria (1.00)
Hi-C - Arima v2	ilSelTetr1	2021-05-16	37941_1#3	752,905,658	113,688,754,358	SAMEA7701643	qc complete	Selenia tetralunaria (1.00)

Below are results from a screen of the PacBio data using Mash screen against RefSeq assemblies. Only results with identity over 90% are displayed.

Loading, please wait

identity	info
0.915885	NC_018417.1 Candidatus Carsonella ruddii HT isolate Thao2000, complete genome

Showing 1 to 1 of 1 rows

Species composition by small subunit (SSU) presence in the assembly.

Loading, please wait

specimen	contig	SSU length	attributed taxonomy by SSU
No matching records found

Re-assembly of reads classified under each identified SSU Marker family.

Loading, please wait

specimen	family	classified reads			original assembly				re-assembly
specimen	family	count	(%)	BUSCO	BUSCO	contigs	contig length	reads	BUSCO	contigs	contig length	additional reads	circos
No matching records found

Visualisation of a classification of the PacBio reads using a variation autoencoder on the k-mer counts.

Loading, please wait

specimen	visualisation
ilSelTetr1

Canonical tetranucleotide counts for each contig or scaffold reduced to two dimensions with UMAP to allow visualisation.

Features (colours represent quantile bins):

Hexamer: Estimated coding density (expected to be higher in microbes than in animals).
FastK: The median number of times each 60-mer in the sequence occures across the whole assembly (illustrates repetitiveness)
Unique_15mers: Number of unique 15-mers per base pair (illustrates sequence diversity)
Is_Connected: Presence of at least one Hi-C connection to another scaffold (absence of connections can indicate contamination)
Connections_Base: Number of Hi-C connections per base pair

specimen	asm	date	contig N50	contigs	scaffold N50	scaffolds	length	BUSCO	merqury
No matching records found

Loading, please wait

specimen	asm	date	length	genes	frameshifts	is circular	reference
No matching records found

Selenia tetralunaria
